Trailer Hitch Hidden Hitch HITCH BALLS CLASS I & II

HITCH BALLS CLASS I & II

HOW TO SELECT THE CORRECT HITCH BALL

Select the correct ball for the coupler on your trailer
The ball diameter required is stamped into the coupler handle or body
Ensure the trailer ball shank fits the thickness & diameter of your drawbar, ball mount or step bumper.
Tech Tips:
LOCK NUT MUST BE PUT ON AFTER LOCK WASHER

Ball Dia.A

Finish

Shank
Dia.
B

Shank
Length
C

Drawbar
Thickness
Range

G.T.W.
G.V.W.R.
Rating

Price

Zinc

Chrome

1-7/8"

63810

3/4"

1-1/2"

3/8"-5/8"

2,000

$7.87

63811

3/4"

1-1/2"

3/8"-5/8"

2,000

$6.55

63812

3/4"

2-3/8"

3/8"-1-3/8"

2,000

$8.03

63813

3/4"

2-3/8"

3/8"-1-3/8"

2,000

$7.65

63814

3/4"

3-3/8"

3/8"-2-1/8"

2,000

$10.34

63820

3/4"

1-1/2"

3/8"-5/8"

3,500

$8.03

63821

3/4"

1-1/2"

3/8"-5/8"

3,500

$6.82

63822

3/4"

2-3/8"

3/8-1-3/8"

3,500

$8.75

63823

3/4"

2-5/16"

3/8-1-1/4"

3,500

$7.48

63824

3/4"

3-3/8"

3/8"-2-1/8"

3,500

$12.05

BALL COVERS

Protect your hitch ball from the elements

Part #	Qty.	Description	Price
42250	1	1-7/8" – 2" Ball Cover	$3.25
42551	1	2-5/16" Ball Cover	$2.25

Interchangeable Ball Systems

Interchangeable ball system is the easiest and safest solution for people who tow multiple trailers. With its exclusive J-Groove design, the Switch Ballmounts to the shank with a twist of the wrist. It stays locked securely while the coupler is fastened to the ball.

• No tools required
• No attachment pin to remove
• Hot forged from premium grade steel

Part #	Qty.	Description	Price
63801	1	Interchangeable Hitch Ball, 3/4" Shank, 1-7/8" & 2" Balls, 5,000 lb. Rating	$23.95
63802	1	Interchangeable Hitch Ball, 1" Shank, 1-7/8" & 2" Balls, 8,000 lb. Rating	$26.95
63804	1	Interchangeable Hitch Ball, 1" Shank, 2" & 2-5/16" Balls, 8,000 lb. Rating	$28.95
63803	1	Interchangeable Hitch Ball, 1" Shank, 1-7/8", 2", & 2-5/16" Balls, 8,000 lb. Rating	$34.95

REPLACEMENT PARTS

Part #	Qty.	Description	Price
63805	1	Replacement 1-7/8" Interchangeable Hitch Ball Head	$6.95
63806	1	Replacement 2" Interchangeable Hitch Ball Head	$7.95
63807	1	Replacement 2-5/16" Interchangeable Hitch Ball Head	$8.95
63808	1	Replacement 3/4" Interchangeable Hitch Ball Shank	$15.95
63809	1	Replacement 1" Interchangeable Hitch Ball Shank	$17.95
